Modexia AgentPay: Deep Context & Developer Guide

1. Introduction & Overview

Modexia is a financial infrastructure layer built specifically for autonomous AI agents. It bridges Web2 authentication (Supabase) with Web3 Smart Contract Accounts (ERC-4337 on the Base Network).

This allows an AI agent to programmatically control a non-custodial wallet and make fast, cheap payments (USDC) to other agents, services, or users without needing to manage complex crypto infrastructure directly.

2. Architecture & Security Model

2.1 Current State: API Key & Managed Wallets

Currently, ModexiaAgentpay prioritizes developer experience and simple integration. Agents interact with the protocol primarily through API Keys. The Modexia platform acts as a trusted facilitator that manages the underlying blockchain complexity on behalf of the agent.

Flow:

1. Developer Setup: A developer registers on the Modexia platform and receives an API Key. Underlying this account is a Circle Developer-Controlled Wallet (managed by Modexia).
2. Channel Opening (On-Chain): When the developer's agent needs to pay a provider, the backend (using the API Key for auth) triggers a transaction to lock USDC into the ModexiaVault smart contract.
3. Usage (Off-Chain): The agent consumes the provider's API. The Modexia backend tracks the usage and the amount owed off-chain in its database.
4. Settlement: When the consumption ends, the Modexia backend (acting on behalf of the agent) submits the final owed amount to the ModexiaVault contract via settleChannel(). The Vault distributes the USDC to the provider, takes a platform fee, and refunds the rest to the agent's wallet.

2.2 Future State: Trustless State Channels (EIP-712)

Eventually, Modexia will upgrade to Fully Trustless State Channels using cryptographic signatures, where the agent environment manages its own private key and signs "Receipts" (micro-payments) off-chain, which the provider directly submits to the ModexiaVault contract.

3. SDK Capabilities (Python)

Currently, Modexia is interacted with via the Python SDK (modexiaagentpay).

Installation

pip install modexiaagentpay

Initialization

Authentication and environment selection are handled via the API Key prefix:

• mx_test_... -> Targets Sandbox (Base-Sepolia)
• mx_live_... -> Targets Production (Base-Mainnet)

from modexia import create_client
client = create_client(api_key="mx_test_...")

Core Operations

1. Checking Balance

Returns the available USDC balance of the Agent's Smart Contract Wallet.

balance = client.retrieve_balance() # or client.get_balance()
print(f"Balance: {balance} USDC")

2. Direct Payment (Transfer Funds)

Sends USDC to a specific wallet address. The platform charges a 1% fee on top of the amount.

receipt = client.transfer(
    recipient="0x7d5...",
    amount=5.00,       # Amount in USDC (Decimal)
    wait=True,         # Poll for blockchain finality (Recommended)
    idempotency_key="task_123" # Optional: Prevent double-spend
)

3. Smart Fetch (x402 / Paywall Negotiation)

A wrapper around HTTP GET. Automatically detects 402 Payment Required, parses the WWW-Authenticate header for price/destination, pays the invoice via Modexia, and retries the request with a proof-of-payment header.

# Automatically pays if status is 402
response = client.smart_fetch("https://premium-api.com/data")

4. Vault Channels (Micro-payments)

For high-frequency or streaming capability:

1. client.open_channel(provider, depositAmount) locks funds on-chain.
2. client.consume_channel(channelId, amount) pays a small amount instantly via backend tracking.
3. client.settle_channel(channelId) closes the channel and settles on-chain.

4. Building RAG & AI Agents with Modexia

When building AI Agents using Modexia (especially with TS tools like Vercel AI SDK or MCP), the Agent needs precise context.

RAG Integration

If your agent receives a request to perform a payment, but needs to check policies or external constraints first, it should leverage Retrieval-Augmented Generation (RAG). By reading this documentation (often exposed via MCP resources), the AI can understand that a transfer must be provided a valid 0x... string and a decimal amount.

Best Practices for AI Integration

• Idempotency Keys: Agents should ALWAYS generate a unique standard string (like a combination of the task ID and step) for the idempotency_key when calling payment features to avoid double-charging if the AI retries the action.
• Error Handling: AI agents should be aware of ModexiaPaymentError (insufficient funds, limit exceeded) and ModexiaAuthError. If a 402 Error is received dynamically, agents can use the smart_fetch command or manually instruct the transfer command.
• Gas Fees: The AI should know that it does NOT need ETH. Gas fees are sponsored by the Modexia Paymaster. Limits are purely enforced in USDC.
