OpenCharts MCP

official

Plug your AI agent into OpenCharts—build spreadsheets, boards, music, and automations from Claude Code, Codex, or Cursor without leaving your terminal.

GitHub

What can you do with Open Charts MCP?

Create and manage projects — Build flowcharts, whiteboards, notes, presentations, and more using tools like create_flowchart, create_whiteboard, create_notes, and create_presentation.
Work with spreadsheets — Inspect, read, create, and edit Theo Sheets with formula support using inspect_sheet, get_sheet, create_sheet, update_sheet, and edit_sheet.
Build and run automations — Create, configure, activate, and run Theo Agents with build_agent, create_agent, configure_agent_trigger, and run_agent.
Manage Kanban boards — Create boards, add and update cards, and manage lists with create_board, add_board_card, update_board_card, and list_board_cards.
Generate websites and songs — Build full websites or apps with generate_code_canvas and create music with create_song, then poll status with get_code_canvas_status and get_song_status.
Check account and credits — Verify your connection with whoami and monitor AI credit usage with get_credits.

Documentation

OpenCharts MCP Server

Build flowcharts, notes, slides, sheets, boards, sites, agents & songs in OpenCharts — straight from your AI client.

Website · Documentation · Get an API key · Issues

What is this?

OpenCharts runs a public, hosted Model Context Protocol (MCP) server that puts the whole OpenCharts product inside any MCP-compatible AI client. Connect once with an API key and your assistant can build and manage real OpenCharts projects on your behalf — flowcharts, whiteboards, notes, presentations, spreadsheets (Theo Sheets), Kanban + calendar boards, full websites & apps (Code Canvas), automations (Theo Agents), and songs (Theo Symphony) — all powered by Theo, the OpenCharts AI.

It is a remote server over Streamable HTTP — there is nothing to install or run locally. Point your client at the endpoint, paste your API key, and go.

This repository is the public documentation for that server. The server itself is hosted by OpenCharts; you don't run it yourself.

Want to connect in under a minute? Use the in-app guide at opencharts.com/help/mcp-server or the setup page at opencharts.com/theo-agents/mcp.

Quick start

Create an API key at opencharts.com/theo-agents/mcp. Copy it immediately — the full key is shown only once.
Add the server to your AI client using the matching config snippet below, replacing {{YOUR_API_KEY}} with your key.
Verify the connection by asking your assistant to call the whoami tool — it should return your OpenCharts account.

Endpoint

https://www.opencharts.com/api/mcp

Transport: Streamable HTTP (POST)
Auth: Authorization: Bearer <API key> (a JWT from an active OpenCharts session also works)

⚠️ Always use the www. host. The apex opencharts.com issues a 307 redirect that strips the Authorization header and breaks authentication. Use https://www.opencharts.com/api/mcp exactly.

Connect your AI client

The server works with any MCP-compatible client. Copy the matching snippet and swap in your API key. Prefer to let your assistant wire it up? The help page has a one-paste "AI setup prompt" for every client below.

Warp

{
  "mcpServers": {
    "opencharts": {
      "type": "http",
      "url": "https://www.opencharts.com/api/mcp",
      "headers": {
        "Authorization": "Bearer {{YOUR_API_KEY}}"
      }
    }
  }
}

Claude Desktop / Claude Code

{
  "mcpServers": {
    "opencharts": {
      "type": "streamable-http",
      "url": "https://www.opencharts.com/api/mcp",
      "headers": {
        "Authorization": "Bearer {{YOUR_API_KEY}}"
      }
    }
  }
}

Cursor

{
  "mcpServers": {
    "opencharts": {
      "url": "https://www.opencharts.com/api/mcp",
      "headers": {
        "Authorization": "Bearer {{YOUR_API_KEY}}"
      }
    }
  }
}

VS Code (GitHub Copilot)

Add to .vscode/mcp.json:

{
  "servers": {
    "opencharts": {
      "type": "http",
      "url": "https://www.opencharts.com/api/mcp",
      "headers": {
        "Authorization": "Bearer ${input:opencharts-key}"
      }
    }
  },
  "inputs": [
    {
      "id": "opencharts-key",
      "type": "promptString",
      "description": "OpenCharts API key",
      "password": true
    }
  ]
}

Windsurf (Codeium)

{
  "mcpServers": {
    "opencharts": {
      "serverUrl": "https://www.opencharts.com/api/mcp",
      "headers": {
        "Authorization": "Bearer {{YOUR_API_KEY}}"
      }
    }
  }
}

Claude Code (CLI)

claude mcp add --transport http opencharts https://www.opencharts.com/api/mcp --header "Authorization: Bearer {{YOUR_API_KEY}}"

Codex (OpenAI)

codex mcp add opencharts --url https://www.opencharts.com/api/mcp --header "Authorization: Bearer {{YOUR_API_KEY}}"

Amp

In the VS Code extension settings.json:

"amp.mcpServers": {
  "opencharts": {
    "url": "https://www.opencharts.com/api/mcp",
    "headers": {
      "Authorization": "Bearer {{YOUR_API_KEY}}"
    }
  }
}

OpenCode

{
  "$schema": "https://opencode.ai/config.json",
  "mcp": {
    "opencharts": {
      "type": "remote",
      "url": "https://www.opencharts.com/api/mcp",
      "oauth": false,
      "headers": {
        "Authorization": "Bearer {{YOUR_API_KEY}}"
      }
    }
  }
}

Tools

The server exposes 56 tools across 10 groups. Tools that use Theo AI or generation consume AI credits.

Projects

Tool	Description
`list_projects`	List your projects with pagination and filters
`get_project`	Get full project data by ID
`create_flowchart`	Create a flowchart project with nodes and edges
`create_whiteboard`	Create a whiteboard with native shapes and elements
`create_notes`	Create a notes project from Markdown
`create_presentation`	Create a slide deck from an outline
`update_project`	Update metadata or content (notes, flowchart, whiteboard, or presentation)
`delete_project`	Soft-delete a project (30-day recovery)

Code Canvas

Tool	Description
`generate_code_canvas`	Build a full website or app (HTML/React) from a description — returns a job to poll
`get_code_canvas_status`	Poll a Code Canvas build; returns the project + open URL when ready

AI

Tool	Description
`ask_theo`	Send a single-turn AI message (fast or think mode)
`extract_flowchart`	Extract a flowchart from an uploaded document (PDF, image, PPTX)

Theo Agents

Tool	Description
`build_agent`	Build a Theo Agent from a description — runs in the background, notifies you when ready
`get_agent_build_status`	Optional poll for a `build_agent` job; returns the agent + open URL when done
`create_agent`	Create a Theo Agent deterministically from structured steps + trigger
`update_agent`	Patch an agent's name, description, or step list
`configure_agent_trigger`	Set an agent's trigger (manual, schedule, webhook, event, telegram)
`activate_agent`	Activate an agent (seeds the first scheduled run)
`deactivate_agent`	Deactivate an agent so triggers stop firing
`delete_agent`	Soft-delete an agent (30-day recovery)
`list_agents`	List your Theo Agents with status + step counts
`get_agent`	Get an agent's full definition (trigger + ordered steps)
`run_agent`	Dispatch an agent now — runs in the background, notifies you on completion
`list_agent_runs`	List an agent's recent execution runs
`get_agent_run_status`	Get a single run's status + per-node progress

Theo Sheets

Tool	Description
`list_sheets`	List your Theo Sheets spreadsheet projects
`inspect_sheet`	Inspect a sheet — per-tab dimensions, header row, sampled cells + formulas, layout
`get_sheet`	Extract a worksheet as structured rows (headers + data rows)
`read_sheet_range`	Read an exact A1 range's values (+ optional formulas) as a grid + CSV
`create_sheet`	Create a live spreadsheet (Excel-grade grid + formulas) from headers and rows
`update_sheet`	Edit a sheet by applying structured spreadsheet edit ops — saved as a rollback-able commit
`apply_sheet_ops`	Apply structured spreadsheet edit ops — or propose a merge-gated change
`edit_sheet`	Edit a sheet with a natural-language instruction (Theo plans + applies ops)
`list_sheet_commits`	List a sheet's git-style change commits (applied / proposed / merged)
`diff_sheet_commit`	Show the cell-level diff for a commit or proposal
`resolve_sheet_proposal`	Merge or reject a pending change proposal
`rollback_sheet`	Roll the live sheet back to a prior commit (reversible)

Boards

Tool	Description
`create_board`	Create a Kanban + calendar project board
`list_boards`	List your project boards
`get_board`	Get a board's lists (columns) and cards
`update_board`	Update a board's name, description, or list columns
`delete_board`	Soft-delete a board (recoverable)
`duplicate_board`	Duplicate a board with its lists, rules, and cards
`add_board_card`	Add a card (post/task/idea/event) to a board
`list_board_cards`	List a board's cards, optionally by schedule range
`update_board_card`	Edit a card — move list, reschedule, change status/color
`delete_board_card`	Soft-delete a card from a board

Theo Symphony

Tool	Description
`create_song`	Generate a song with Theo Symphony — returns a job to poll
`get_song_status`	Poll a song job; returns audio + cover-art versions when complete

Notes

Tool	Description
`get_note_content`	Extract a note's content as Markdown
`append_to_note`	Append Markdown content to an existing note
`clip_to_note`	Save web content (URL + HTML) as a clip inside a note

Templates

Tool	Description
`list_templates`	Browse the template gallery
`use_template`	Create a new project from a template

Account

Tool	Description
`whoami`	Get the authenticated user's profile information
`get_credits`	Check remaining AI credit balance

Resources

Resources provide read-only context an AI client can retrieve without calling a tool.

Resource	Description
`projects`	Paginated list of your recent projects
`project`	Full data for a single project by ID
`templates`	Browsable template catalog

How it works

┌────────────────────┐   Streamable HTTP    ┌────────────────────────────┐
│   Your AI client    │   + Bearer API key   │   OpenCharts MCP (hosted)  │
│  Warp · Claude ·    │ ───────────────────► │                            │
│  Cursor · VS Code · │                      │  Projects · Code Canvas ·  │
│  Windsurf · Codex · │ ◄─────────────────── │  Agents · Sheets · Boards ·│
│  Amp · OpenCode     │      tool results    │  Symphony · Notes · AI     │
└────────────────────┘                      └────────────────────────────┘

Every request is authenticated by your API key and acts on your own OpenCharts account. Because the server is hosted, the tool surface stays current automatically — no client updates required. Tools that use Theo AI or generation (for example ask_theo, extract_flowchart, generate_code_canvas, build_agent, create_song) consume AI credits from your plan.

Rate limits & credits

120 requests per minute per user.
AI and generation tools consume AI credits — check your balance any time with the get_credits tool.

Discovery & registry

Machine-readable metadata is published for clients, crawlers, and registries (no secrets):

https://www.opencharts.com/.well-known/mcp — discovery manifest
https://www.opencharts.com/.well-known/mcp/server-card.json — server card
https://www.opencharts.com/.well-known/oauth-protected-resource — protected-resource metadata
Docs: opencharts.com/help/mcp-server

Troubleshooting

307 redirect / "no authorization support" / 401 — make sure the URL is exactly https://www.opencharts.com/api/mcp (with www.). The apex host strips the Authorization header on redirect. Also confirm your key is active and sent with the Bearer prefix.
429 Too Many Requests — you've hit the 120 req/min limit; wait and retry.
Tools missing in your client — fully restart the client (or toggle the OpenCharts server off/on) so it re-fetches the tool list. Confirm your key carries the read, write, and ai scopes (default keys include all three).
JWT expired mid-session — session JWTs expire after ~15 minutes; use a persistent API key for long-running integrations.

Compatible clients

Works with any client that supports the Model Context Protocol, including:

Warp — agentic development environment
Claude Desktop & Claude Code
Cursor
VS Code (GitHub Copilot)
Windsurf (Codeium)
Codex (OpenAI)
Amp
OpenCode

License

This documentation is licensed under CC-BY-4.0. The OpenCharts MCP server is a hosted product — see opencharts.com for terms and pricing.
