repo-graph

Structural graph memory for AI coding assistants. Map your codebase. Navigate by structure. Read only what matters.

repo-graph gives LLMs a map of your codebase — entities, relationships, and flows — so they can navigate to the right files without reading everything first.

Instead of flooding an LLM's context window with your entire codebase (or hoping it guesses right), repo-graph builds a lightweight graph of what exists, how things connect, and where the entry points are. The LLM queries the graph, finds the minimal set of files it needs, and reads only those.

Demo

https://github.com/user-attachments/assets/a1e4171b-b225-40d4-9210-39453e14b76a

https://github.com/user-attachments/assets/fc3191e5-fc35-4bd7-8372-72af55995883

Same bug, same model, same prompt — the only difference is whether repo-graph is installed.

The task: fix a reversed comparison operator in a Go + Angular monorepo (566 nodes, 620 edges).

	Without repo-graph	With repo-graph
Tokens used	75,308	29,838
Time to fix	4m 36s	~30s
Files explored	~15 (grep, read, grep, read...)	2 (flow lookup + handler file)
Outcome	Found and fixed the bug	Found and fixed the bug

2.5x fewer tokens. ~9x faster. Same correct fix.

How the test was run

Both runs used identical conditions to keep the comparison fair:

• Same model: Claude Opus, 100% (no Haiku routing)
• Same prompt: "Groups that were created recently are showing as closed, and old groups show as open. This is backwards — new groups should be open for members to join. Find and fix the bug."
• Fresh context: each run started from /clear with no prior conversation
• No other tools: CLAUDE.md, plugins, hooks, and all other MCP servers were removed for both runs — the only variable was whether repo-graph was installed
• No hints: the prompt describes the symptom, not the location — Claude has to find group_controller.go:57 on its own

Without repo-graph, Claude greps for keywords, reads files, greps again, reads more files, and eventually narrows down to the bug. With repo-graph, Claude calls flow("groups"), gets back the exact handler function and file, reads it, and fixes it.

Browse pre-generated examples for FastAPI, Gin, Hono, and NestJS — real graph output you can inspect without installing anything.

The problem

LLMs working on code waste most of their context on orientation:

• Reading files that turn out to be irrelevant
• Missing connections between components in different languages
• Not knowing where a feature starts or what it touches
• Loading 50 files when 5 would do

This is expensive, slow, and gets worse as codebases grow.

How repo-graph solves it

repo-graph scans your codebase once and builds a graph of:

• Entities: modules, packages, classes, functions, routes, services, components
• Relationships: imports, calls, handles, defines, contains, cross-stack HTTP
• Flows: end-to-end paths from entry point to data layer

Then it exposes 13 MCP tools that let the LLM:

1. Orient — "What languages are in this repo? What are the main features?"
2. Navigate — "Trace the login flow from route to database" / "What's the shortest path between UserService and the payments API?"
3. Scope — "How many lines would I need to read to understand this feature?" / "Give me just the files I need for this bug fix"
4. Assess — "What's the blast radius of changing this function?" / "Which files are the biggest maintenance risks?"

The LLM gets structural context in a few hundred tokens instead of reading thousands of lines.

Supported languages

Language	Detection	What it extracts
Go	go.mod	Packages, functions, HTTP routes (gin/echo/chi/stdlib), imports
Rust	Cargo.toml	Crates, modules, structs, traits, functions, routes (Actix/Rocket/Axum)
TypeScript	tsconfig.json / package.json	Modules, classes, functions, import relationships
React	react in package.json	Components, hooks, context providers, React Router routes, fetch/axios calls, flows
Angular	@angular/core in package.json	Components, services, guards, DI injection, HTTP calls, feature flows
Vue	vue in package.json	SFCs, composables, Vue Router routes, fetch/axios calls
Python	pyproject.toml / setup.py / requirements.txt	Packages, modules, classes, functions, routes (Flask/FastAPI/Django)
Java/Kotlin	pom.xml / build.gradle	Packages, classes, routes (Spring/JAX-RS/Ktor/WebFlux/Micronaut)
Scala	build.sbt	Packages, objects/classes/traits, routes (Play/Akka HTTP/http4s)
Clojure	project.clj / deps.edn	Namespaces, defn/defprotocol/defrecord, routes (Compojure/Reitit)
C#/.NET	.csproj / .sln	Namespaces, classes, routes (ASP.NET/Minimal API)
Ruby	Gemfile / .gemspec	Files, classes, modules, Rails routes
PHP	composer.json	Namespaces, classes, interfaces, routes (Laravel/Symfony)
Swift	Package.swift / .xcodeproj	Files, types (class/struct/enum/protocol/actor), Vapor routes
C/C++	CMakeLists.txt / Makefile / meson.build	Sources, headers, classes, structs, enums, namespaces, includes
Dart/Flutter	pubspec.yaml	Modules, classes, widgets, go_router/shelf routes
Elixir/Phoenix	mix.exs	Modules, functions, Phoenix router scopes + routes
Solidity	.sol files / foundry.toml / hardhat.config.*	Contracts, interfaces, libraries, events, inheritance
Terraform	.tf files	Modules, resources, variables, outputs, module sources
SCSS	.scss files present	File-level bloat analysis

Cross-cutting extractors (work across all languages):

• Data sources — DB/cache/queue/blob/search/email client detection
• CLI entrypoints — Python click, JS commander/yargs, Go cobra, Rust clap
• gRPC — service/method definitions from .proto files
• Queue consumers — Celery, Dramatiq, BullMQ, Sidekiq, Oban, NATS
• Cross-stack HTTP — frontend fetch/axios calls linked to backend routes

Multiple languages can match one repo (e.g., Go backend + Angular frontend + SCSS). Each contributes its nodes and edges into a single unified graph.

Install

pip install mcp-repo-graph

Python 3.11+. Installs two packages: mcp-repo-graph (the MCP server) and repo-graph-py (the Rust engine, as a prebuilt wheel).

Quick start

1. Initialise the target repo

repo-graph-init --repo /path/to/your/project

This generates the graph, writes .mcp.json and CLAUDE.md instructions, and gets your AI assistant ready to use repo-graph.

2. Connect to your AI assistant

If you skipped repo-graph-init, add this to your MCP configuration manually:

Claude Code (~/.claude/claude_code_config.json or project .mcp.json):

{
  "mcpServers": {
    "repo-graph": {
      "command": "repo-graph",
      "args": ["--repo", "/path/to/your/project"]
    }
  }
}

With environment variable:

{
  "mcpServers": {
    "repo-graph": {
      "command": "repo-graph",
      "env": { "REPO_GRAPH_REPO": "/path/to/your/project" }
    }
  }
}

3. Use it

The AI assistant now has access to all 13 tools. Example queries it can answer:

• "What does this codebase do?" → status tool
• "Trace the checkout flow" → flow tool
• "What would break if I change UserService?" → impact tool
• "What files do I need for this bug?" → minimal_read tool
• "This file is too big, how should I split it?" → split_plan tool
• "Show me the auth flow visually" → graph_view tool

4. Keep it fresh with a git hook (recommended)

Add a call to generate via your MCP client to a pre-commit hook so the graph stays up to date automatically — no LLM context spent on regeneration:

# .git/hooks/pre-commit (or add to your existing hook)
#!/bin/sh
repo-graph --repo . --regenerate
git add .ai/repo-graph/

chmod +x .git/hooks/pre-commit

Every commit keeps the graph current. The LLM always has a fresh map without wasting a single token on generate.

Tip: If you don't want graph data in version control, add .ai/repo-graph/ to .gitignore and skip the git add line — the graph will just live locally.

MCP tools reference

Generation

Tool	Parameters	Description
generate	(none)	Scan the codebase from scratch, rebuild the graph, and reload
reload	(none)	Reload graph data from disk (after external regeneration)

Navigation

Tool	Parameters	Description
status	(none)	Repo overview: git state, detected languages, entity counts, available flows
flow	feature	End-to-end flow for a feature — from entry point through service layer to data
trace	from_id, to_id	Shortest path between any two nodes in the graph
impact	node_id, direction (upstream/downstream), depth	Fan out from a node to see what it affects or depends on
neighbours	node_id	All direct connections to and from a node

Context budgeting

Tool	Parameters	Description
cost	feature	Total line count for all files in a feature's flow
hotspots	top_n	Files ranked by size * connections — maintenance risk indicators
minimal_read	feature, task_hint	Smallest file set needed for a specific task within a feature

Health analysis

Tool	Parameters	Description
bloat_report	file_path	Internal structure of a file: functions/methods ranked by size, type counts
split_plan	file_path	Concrete suggestions for splitting an oversized file, grouped by responsibility
graph_view	feature or node, depth	Visual ASCII map of a feature flow, node neighbourhood, or full graph overview

How it works

mcp-repo-graph is a thin Python MCP server that wraps glia, a Rust engine.

1. Parse — per-language tree-sitter parsers extract raw nodes and unresolved references
2. Extract — cross-cutting extractors layer on HTTP routes, data sources, CLI entrypoints, gRPC services, queue consumers
3. Resolve — graph builder resolves intra-repo references; cross-graph resolvers link stacks (frontend HTTP calls → backend routes, etc.)
4. Store — merged graph lands in .ai/repo-graph/ as a zero-copy .gmap (rkyv + mmap) plus JSON projections for portability
5. Serve — the MCP server loads the graph into memory and exposes the 13 tools

The Rust engine will split into its own glia repo post-v0.4.12. mcp-repo-graph will remain the MCP-facing thin wrapper.

Config (optional escape hatch)

If auto-detection misses a weird layout, drop .ai/repo-graph/config.yaml in the target repo:

skip:
  - legacy       # directory basenames excluded from the walk
  - scratch

roots:           # explicit roots heuristics miss — added on top of auto-detection
  - path: apps/weird-layout
    kind: python
  - path: services/custom
    kind: go

kind values: go, rust, python, typescript, react, vue, angular, java, scala, clojure, csharp, ruby, php, swift, c_cpp, dart, elixir, solidity, terraform. config.json works too if you prefer.

Graph data format

Generated files live in .ai/repo-graph/ inside the target repo:

• nodes.json — [{id, type, name, file_path, confidence, ...}, ...]
• edges.json — [{from, to, type}, ...]
• flows/*.yaml — named feature flows with ordered step sequences and kind (http/page/cli/grpc/queue)
• state.md — human-readable snapshot for quick orientation

Common edge types: imports, defines, contains, uses, calls, handles, handled_by, exports, includes, tests, cross-stack HTTP links.

License

MIT
