Litmus MCP Server

The official Litmus Automation Model Context Protocol (MCP) Server enables LLMs and intelligent systems to interact with Litmus Edge for device configuration, monitoring, and management. It is built on top of the MCP SDK and adheres to the Model Context Protocol spec.

Quick Launch
STDIO - Claude Desktop
Tips
Tools
Litmus Central

Quick Launch

Start an HTTP SSE MCP Server using Docker

Run the server in Docker (HTTP SSE only)

docker run -d --name litmus-mcp-server -p 8000:8000 ghcr.io/litmusautomation/litmus-mcp-server:latest

NOTE: The Litmus MCP Server is built for linux/AMD64 platforms. If running in Docker on ARM64, specify the AMD64 platform type by including the --platform argument:

docker run -d --name litmus-mcp-server --platform linux/amd64 -p 8000:8000 ghcr.io/litmusautomation/litmus-mcp-server:main

Web UI

The Docker image includes a built-in chat interface that lets you interact with Litmus Edge using natural language — no MCP client configuration required.

Start the server with both ports exposed:

docker run -d --name litmus-mcp-server \
  -p 8000:8000 -p 9000:9000 \
  -e ANTHROPIC_API_KEY=<key> \
  ghcr.io/litmusautomation/litmus-mcp-server:latest

:9000 — Web UI (chat interface). Open http://localhost:9000 in your browser, add a Litmus Edge instance via the config page, and start chatting.
:8000 — SSE endpoint for external MCP clients (Claude Desktop, Cursor, VS Code, etc.) — still available as normal.

If you deploy the MCP server and web client on separate hosts, set MCP_SSE_URL to point the web client at the server:

-e MCP_SSE_URL=http://<mcp-server-host>:8000/sse

Persistent Configuration

By default, configuration saved through the Web UI (API keys, Litmus Edge instances, model preferences, connection settings) is written to .env inside the container and is lost when the container is removed.

To retain configuration across container restarts and replacements, mount a host file over /app/.env:

# One-time setup — the host file must exist before docker run
mkdir -p /opt/litmus-mcp
touch /opt/litmus-mcp/.env

# Run with the volume mount
docker run -d --name litmus-mcp-server \
  -p 8000:8000 -p 9000:9000 \
  -v /opt/litmus-mcp/.env:/app/.env \
  ghcr.io/litmusautomation/litmus-mcp-server:latest

Any configuration you save in the UI is written to /opt/litmus-mcp/.env on the host. A new container started with the same -v flag will pick it up automatically on startup.

Note: The host-side file must be created with touch before running the container. If it does not exist, Docker creates a directory at that path and the application will fail to write configuration.

Docker Compose equivalent:

services:
  litmus-mcp-server:
    image: ghcr.io/litmusautomation/litmus-mcp-server:latest
    ports:
      - "8000:8000"
      - "9000:9000"
    volumes:
      - /opt/litmus-mcp/.env:/app/.env

Claude Code CLI

Run Claude from a directory that includes a configuration file at ~/.claude/mcp.json:

{
  "mcpServers": {
    "litmus-mcp-server": {
      "type": "sse",
      "url": "http://localhost:8000/sse",
      "headers": {
        "EDGE_URL": "${EDGE_URL}",
        "EDGE_API_CLIENT_ID": "${EDGE_API_CLIENT_ID}",
        "EDGE_API_CLIENT_SECRET": "${EDGE_API_CLIENT_SECRET}",
        "NATS_SOURCE": "${NATS_SOURCE}",
        "NATS_PORT": "${NATS_PORT:-4222}",
        "NATS_USER": "${NATS_USER}",
        "NATS_PASSWORD": "${NATS_PASSWORD}",
        "INFLUX_HOST": "${INFLUX_HOST}",
        "INFLUX_PORT": "${INFLUX_PORT:-8086}",
        "INFLUX_DB_NAME": "${INFLUX_DB_NAME:-tsdata}",
        "INFLUX_USERNAME": "${INFLUX_USERNAME}",
        "INFLUX_PASSWORD": "${INFLUX_PASSWORD}"
      }
    }
  }
}

Anthropic Docs

Cursor IDE

Add to ~/.cursor/mcp.json or .cursor/mcp.json:

{
  "mcpServers": {
    "litmus-mcp-server": {
      "url": "http://<MCP_SERVER_IP>:8000/sse",
      "headers": {
        "EDGE_URL": "https://<LITMUSEDGE_IP>",
        "EDGE_API_CLIENT_ID": "<oauth2_client_id>",
        "EDGE_API_CLIENT_SECRET": "<oauth2_client_secret>",
        "NATS_SOURCE": "<LITMUSEDGE_IP>",
        "NATS_PORT": "4222",
        "NATS_USER": "<access_token_username>",
        "NATS_PASSWORD": "<access_token_from_litmusedge>",
        "INFLUX_HOST": "<LITMUSEDGE_IP>",
        "INFLUX_PORT": "8086",
        "INFLUX_DB_NAME": "tsdata",
        "INFLUX_USERNAME": "<datahub_username>",
        "INFLUX_PASSWORD": "<datahub_password>"
      }
    }
  }
}

Cursor docs

VS Code / GitHub Copilot

Manual Configuration

In VS Code: Open User Settings (JSON) → Add:

{
  "mcpServers": {
    "litmus-mcp-server": {
      "url": "http://<MCP_SERVER_IP>:8000/sse",
      "headers": {
        "EDGE_URL": "https://<LITMUSEDGE_IP>",
        "EDGE_API_CLIENT_ID": "<oauth2_client_id>",
        "EDGE_API_CLIENT_SECRET": "<oauth2_client_secret>",
        "NATS_SOURCE": "<LITMUSEDGE_IP>",
        "NATS_PORT": "4222",
        "NATS_USER": "<access_token_username>",
        "NATS_PASSWORD": "<access_token_from_litmusedge>",
        "INFLUX_HOST": "<LITMUSEDGE_IP>",
        "INFLUX_PORT": "8086",
        "INFLUX_DB_NAME": "tsdata",
        "INFLUX_USERNAME": "<datahub_username>",
        "INFLUX_PASSWORD": "<datahub_password>"
      }
    }
  }
}

Or use .vscode/mcp.json in your project.

VS Code MCP Docs

Windsurf

Add to ~/.codeium/windsurf/mcp_config.json:

{
  "mcpServers": {
    "litmus-mcp-server": {
      "url": "http://<MCP_SERVER_IP>:8000/sse",
      "headers": {
        "EDGE_URL": "https://<LITMUSEDGE_IP>",
        "EDGE_API_CLIENT_ID": "<oauth2_client_id>",
        "EDGE_API_CLIENT_SECRET": "<oauth2_client_secret>",
        "NATS_SOURCE": "<LITMUSEDGE_IP>",
        "NATS_PORT": "4222",
        "NATS_USER": "<access_token_username>",
        "NATS_PASSWORD": "<access_token_from_litmusedge>",
        "INFLUX_HOST": "<LITMUSEDGE_IP>",
        "INFLUX_PORT": "8086",
        "INFLUX_DB_NAME": "tsdata",
        "INFLUX_USERNAME": "<datahub_username>",
        "INFLUX_PASSWORD": "<datahub_password>"
      }
    }
  }
}

Windsurf MCP Docs

STDIO with Claude Desktop

This MCP server supports local connections with Claude Desktop and other applications via Standard file Input/Output (STDIO): https://modelcontextprotocol.io/legacy/concepts/transports

To use STDIO: Clone, edit config.py to enable STDIO, run the server as a local process, and update Claude Desktop MCP server configuration file to use the server:

Clone

# Clone
git clone https://github.com/litmusautomation/litmus-mcp-server.git

Set ENABLE_STDIO to 'true' in /src/config.py:

ENABLE_STDIO = os.getenv("ENABLE_STDIO", "true").lower() in ("true", "1", "yes")

Run the server

# Run using uv
uv sync
cd /path/to/litmus-mcp-server
uv run python3 src/server.py

# Otherwise
cd litmus-mcp-server
pip install -e .
python3 src/server.py

Add json server definision to your Claude Desktop config file:

macOS: ~/Library/Application Support/Claude/claude_desktop_config.json
Windows: %APPDATA%\Claude\claude_desktop_config.json
Linux: ~/.config/Claude/claude_desktop_config.json

{
  "mcpServers": {
    "litmus-mcp-server": {
      "command": "/path/to/.venv/bin/python3",
      "args": [
        "/absolute/path/to/litmus-mcp-server/src/server.py"
      ],
      "env": {
        "PYTHONPATH": "/absolute/path/to/litmus-mcp-server/src",
        "EDGE_URL": "https://<LITMUSEDGE_IP>",
        "EDGE_API_CLIENT_ID": "<oauth2_client_id>",
        "EDGE_API_CLIENT_SECRET": "<oauth2_client_secret>",
        "NATS_SOURCE": "<LITMUSEDGE_IP>",
        "NATS_PORT": "4222",
        "NATS_USER": "<access_token_username>",
        "NATS_PASSWORD": "<access_token_from_litmusedge>",
        "INFLUX_HOST": "<LITMUSEDGE_IP>",
        "INFLUX_PORT": "8086",
        "INFLUX_DB_NAME": "tsdata",
        "INFLUX_USERNAME": "<datahub_username>",
        "INFLUX_PASSWORD": "<datahub_password>"
      }
    }
  }
}

Tips

For development, use Python Virtual environments, for example to bridge mcp lib version diffs between dev clients like 'npx @modelcontextprotocol/inspector' & litmus-mcp-server

{
  "mcpServers": {
    "litmus-mcp-server": {
      "command": "/absolute/path/to/litmus-mcp-server/.venv/bin/python",
      "args": ["/absolute/path/to/litmus-mcp-server/src/server.py"],
      "env": { /* same as above */ }
    }
  }
}

See claude_desktop_config_venv.example.json for the complete template.

Header Configuration Guide:

EDGE_URL: Litmus Edge base URL (include https://)
EDGE_API_CLIENT_ID / EDGE_API_CLIENT_SECRET: OAuth2 credentials from Litmus Edge
NATS_SOURCE: Litmus Edge IP (no http/https)
NATS_USER / NATS_PASSWORD: Access token credentials from System → Access Control → Tokens
INFLUX_HOST: Litmus Edge IP (no http/https)
INFLUX_USERNAME / INFLUX_PASSWORD: DataHub user credentials

Available Tools

Category	Function Name	Description
DeviceHub	`get_litmusedge_driver_list`	List supported Litmus Edge drivers (e.g., ModbusTCP, OPCUA, BACnet).
	`get_devicehub_devices`	List all configured DeviceHub devices with connection settings and status.
	`create_devicehub_device`	Create a new device with specified driver and default configuration.
	`get_devicehub_device_tags`	Retrieve all tags (data points/registers) for a specific device.
	`get_current_value_of_devicehub_tag`	Read the current real-time value of a specific device tag.
Device Identity	`get_litmusedge_friendly_name`	Get the human-readable name assigned to the Litmus Edge device.
	`set_litmusedge_friendly_name`	Update the friendly name of the Litmus Edge device.
LEM Integration	`get_cloud_activation_status`	Check cloud registration and Litmus Edge Manager (LEM) connection status.
Docker Management	`get_all_containers_on_litmusedge`	List all Docker containers running on Litmus Edge Marketplace.
	`run_docker_container_on_litmusedge`	Deploy and run a new Docker container on Litmus Edge Marketplace.
NATS Topics *	`get_current_value_from_topic`	Subscribe to a NATS topic and return the next published message.
	`get_multiple_values_from_topic`	Collect multiple sequential values from a NATS topic for trend analysis.
InfluxDB **	`get_historical_data_from_influxdb`	Query historical time-series data from InfluxDB by measurement and time range.
Digital Twins	`list_digital_twin_models`	List all Digital Twin models with ID, name, description, and version.
	`list_digital_twin_instances`	List all Digital Twin instances or filter by model ID.
	`create_digital_twin_instance`	Create a new Digital Twin instance from an existing model.
	`list_static_attributes`	List static attributes (fixed key-value pairs) for a model or instance.
	`list_dynamic_attributes`	List dynamic attributes (real-time data points) for a model or instance.
	`list_transformations`	List data transformation rules configured for a Digital Twin model.
	`get_digital_twin_hierarchy`	Get the hierarchy configuration for a Digital Twin model.
	`save_digital_twin_hierarchy`	Save a new hierarchy configuration to a Digital Twin model.

Tool Use Notes

* NATS Topic Tools Requirements: To use get_current_value_from_topic and get_multiple_values_from_topic, you must configure access control on Litmus Edge:

Navigate to: Litmus Edge → System → Access Control → Tokens
Create or configure an access token with appropriate permissions
Provide the token in your MCP client configuration headers

** InfluxDB Tools Requirements: To use get_historical_data_from_influxdb, you must allow InfluxDB port access:

Navigate to: Litmus Edge → System → Network → Firewall
Add a firewall rule to allow port 8086 on TCP
Ensure InfluxDB is accessible from the MCP server host

Litmus Central

Download or try Litmus Edge via Litmus Central.

MCP server registries

Glama

MCP.so
