MCP TTS VOICEVOX

English | 日本語

A text-to-speech MCP server using VOICEVOX

Features

• Advanced playback control - Flexible audio processing with queue management, immediate playback, and synchronous/asynchronous control
• Prefetching - Pre-generates next audio for smooth playback
• Cross-platform support - Works on Windows, macOS, and Linux (including WSL environment audio playback)
• Stdio/HTTP support - Supports Stdio, SSE, and StreamableHttp
• Multiple speaker support - Individual speaker specification per segment
• Automatic text segmentation - Stable audio synthesis through automatic long text segmentation
• Independent client library - Provided as a separate package @kajidog/voicevox-client

Requirements

• Node.js 18.0.0 or higher
• VOICEVOX Engine or compatible engine

Installation

npm install -g @kajidog/mcp-tts-voicevox

Usage

As MCP Server

1. Start VOICEVOX Engine

Start the VOICEVOX Engine and have it wait on the default port (http://localhost:50021).

2. Start MCP Server

Standard I/O mode (recommended):

npx @kajidog/mcp-tts-voicevox

HTTP server mode:

# Linux/macOS
MCP_HTTP_MODE=true npx @kajidog/mcp-tts-voicevox

# Windows PowerShell
$env:MCP_HTTP_MODE='true'; npx @kajidog/mcp-tts-voicevox

MCP Tools

speak - Text-to-speech

Converts text to speech and plays it.

Parameters:

• text: String (multiple texts separated by newlines, speaker specification in "1:text" format)
• speaker (optional): Speaker ID
• speedScale (optional): Playback speed
• immediate (optional): Whether to start playback immediately (default: true)
• waitForStart (optional): Whether to wait for playback to start (default: false)
• waitForEnd (optional): Whether to wait for playback to end (default: false)

Examples:

// Simple text
{ "text": "Hello\nIt's a nice day today" }

// Speaker specification
{ "text": "Hello", "speaker": 3 }

// Per-segment speaker specification
{ "text": "1:Hello\n3:It's a nice day today" }

// Immediate playback (bypass queue)
{
  "text": "Emergency message",
  "immediate": true,
  "waitForEnd": true
}

// Wait for playback to complete (synchronous processing)
{
  "text": "Wait for this audio playback to complete before next processing",
  "waitForEnd": true
}

// Add to queue but don't auto-play
{
  "text": "Wait for manual playback start",
  "immediate": false
}

Advanced Playback Control Features

Immediate Playback (immediate: true)

Play audio immediately by bypassing the queue:

• Parallel operation with regular queue: Does not interfere with existing queue playback
• Multiple simultaneous playback: Multiple immediate playbacks can run simultaneously
• Ideal for urgent notifications: Prioritizes important messages

Synchronous Playback Control (waitForEnd: true)

Wait for playback completion to synchronize processing:

• Sequential processing: Execute next processing after audio playback
• Timing control: Enables coordination between audio and other processing
• UI synchronization: Align screen display with audio timing

// Example 1: Play urgent message immediately and wait for completion
{
  "text": "Emergency! Please check immediately",
  "immediate": true,
  "waitForEnd": true
}

// Example 2: Step-by-step audio guide
{
  "text": "Step 1: Please open the file",
  "waitForEnd": true
}
// Next processing executes after the above audio completes

Other Tools

• generate_query - Generate query for speech synthesis
• synthesize_file - Generate audio file
• stop_speaker - Stop playback and clear queue
• get_speakers - Get speaker list
• get_speaker_detail - Get speaker details

Package Structure

@kajidog/mcp-tts-voicevox (this package)

• MCP Server - Communicates with MCP clients like Claude Desktop
• HTTP Server - Remote MCP communication via SSE/StreamableHTTP

@kajidog/voicevox-client (independent package)

• General-purpose library - Communication functionality with VOICEVOX Engine
• Cross-platform - Node.js and browser environment support
• Advanced playback control - Immediate playback, synchronous playback, and queue management features

MCP Configuration Examples

Claude Desktop Configuration

Add the following configuration to your claude_desktop_config.json file:

{
  "mcpServers": {
    "tts-mcp": {
      "command": "npx",
      "args": ["-y", "@kajidog/mcp-tts-voicevox"]
    }
  }
}

When SSE Mode is Required

If you need speech synthesis in SSE mode, you can use mcp-remote for SSE↔Stdio conversion:

1. Claude Desktop Configuration

   {
     "mcpServers": {
       "tts-mcp-proxy": {
         "command": "npx",
         "args": ["-y", "mcp-remote", "http://localhost:3000/sse"]
       }
     }
   }


2. Starting SSE Server

   Mac/Linux:

   MCP_HTTP_MODE=true MCP_HTTP_PORT=3000 npx @kajidog/mcp-tts-voicevox


   Windows:

   $env:MCP_HTTP_MODE='true'; $env:MCP_HTTP_PORT='3000'; npx @kajidog/mcp-tts-voicevox


### AivisSpeech Configuration Example

```json
{
  "mcpServers": {
    "tts-mcp": {
      "command": "npx",
      "args": ["-y", "@kajidog/mcp-tts-voicevox"],
      "env": {
        "VOICEVOX_URL": "http://127.0.0.1:10101",
        "VOICEVOX_DEFAULT_SPEAKER": "888753764"
      }
    }
  }
}

Environment Variables

VOICEVOX Configuration

• VOICEVOX_URL: VOICEVOX Engine URL (default: http://localhost:50021)
• VOICEVOX_DEFAULT_SPEAKER: Default speaker ID (default: 1)
• VOICEVOX_DEFAULT_SPEED_SCALE: Default playback speed (default: 1.0)

Playback Options Configuration

• VOICEVOX_DEFAULT_IMMEDIATE: Whether to start playback immediately when added to queue (default: true)
• VOICEVOX_DEFAULT_WAIT_FOR_START: Whether to wait for playback to start (default: false)
• VOICEVOX_DEFAULT_WAIT_FOR_END: Whether to wait for playback to end (default: false)

Usage Examples:

# Example 1: Wait for completion for all audio playback (synchronous processing)
export VOICEVOX_DEFAULT_WAIT_FOR_END=true
npx @kajidog/mcp-tts-voicevox

# Example 2: Wait for both playback start and end
export VOICEVOX_DEFAULT_WAIT_FOR_START=true
export VOICEVOX_DEFAULT_WAIT_FOR_END=true
npx @kajidog/mcp-tts-voicevox

# Example 3: Manual control (disable auto-play)
export VOICEVOX_DEFAULT_IMMEDIATE=false
npx @kajidog/mcp-tts-voicevox

These options allow fine-grained control of audio playback behavior according to application requirements.

Server Configuration

• MCP_HTTP_MODE: Enable HTTP server mode (set to true to enable)
• MCP_HTTP_PORT: HTTP server port number (default: 3000)
• MCP_HTTP_HOST: HTTP server host (default: 0.0.0.0)

Usage with WSL (Windows Subsystem for Linux)

Configuration method for connecting from WSL environment to Windows host MCP server.

1. Windows Host Configuration

Starting MCP server with AivisSpeech and PowerShell:

$env:MCP_HTTP_MODE='true'; $env:MCP_HTTP_PORT='3000'; $env:VOICEVOX_URL='http://127.0.0.1:10101'; $env:VOICEVOX_DEFAULT_SPEAKER='888753764'; npx @kajidog/mcp-tts-voicevox

2. WSL Environment Configuration

Check Windows host IP address:

# Get Windows host IP address from WSL
ip route show | grep default | awk '{print $3}'

Usually in the format 172.x.x.1.

Claude Code .mcp.json configuration example:

{
  "mcpServers": {
    "tts": {
      "type": "sse",
      "url": "http://172.29.176.1:3000/sse"
    }
  }
}

Important Points:

• Within WSL, localhost or 127.0.0.1 refers to WSL internal, so cannot access Windows host services
• Use WSL gateway IP (usually 172.x.x.1) to access Windows host
• Ensure the port is not blocked by Windows firewall

Connection Test:

# Check connection to Windows host MCP server from WSL
curl http://172.29.176.1:3000

If normal, 404 Not Found will be returned (because root path doesn't exist).

Troubleshooting

Common Issues

1. VOICEVOX Engine is not running

   curl http://localhost:50021/speakers


2. Audio is not playing

   • Check system audio output device
   • Check platform-specific audio playback tools:
     • Linux: Requires one of aplay, paplay, play, ffplay
     • macOS: afplay (pre-installed)
     • Windows: PowerShell (pre-installed)

3. Not recognized by MCP client

   • Check package installation: npm list -g @kajidog/mcp-tts-voicevox
   • Check JSON syntax in configuration file

License

ISC

Developer Information

Instructions for developing this repository locally.

Setup

1. Clone the repository:

   git clone https://github.com/kajidog/mcp-tts-voicevox.git
   cd mcp-tts-voicevox


2. Install pnpm (if not already installed).
3. Install dependencies:

   pnpm install


Main Development Commands

You can run the following commands in the project root.

• Build all packages:

  pnpm build


• Run all tests:

  pnpm test


• Run all linters:

  pnpm lint


• Start root server in development mode:

  pnpm dev


• Start stdio interface in development mode:

  pnpm dev:stdio


These commands will also properly handle processing for related packages within the workspace.
